59B 58B
单端面密封 平衡型 任意旋向 Single seal,Banlanced,Independent on direction of rotation -
59U 58U
单端面密封 非平衡型 任意旋向 Single seal,Unbalanced,Independent on direction of rotation -
527 528
单端面密封 非平衡型 任意旋向 Single seal,Unbalanced,Independent on direction of rotation -
E7S
双端面密封 平衡型 任意旋向 多弹簧结构 Double seal , Balanced, Dependent, on direction of rotation Multiple springs. 具有与 E7 系列相同设计性能，除驱动座的安装长度，其他安装尺寸（d<100mm）复合DIN24960标准。 The E7 family of single seals(easy-to-replace seal face, etc.). Apart from the installation length of the drive collar , all fitting dimensions(d1<100 mm) conform with DIN 24960. -
T7
单端面密封 非平衡型 任意旋向 Single seal,Unbalanced,Independent of direction of rotation -
T3
单端面密封 非平衡型 锥形弹簧 旋向固定 Single seal,Unbalanced,Conical spring,Dependent on direction of rotation -
T2
单端面密封 非平衡型 锥形弹簧 旋向固定 Single seal,Unbalanced,Conical spring,Dependent on direction of rotation -
A1
59B 58B
型号：
技术参数：
被密封介质：水、油、中等以下腐蚀性介质
密封腔压力：≤3MPa
密封腔温度：-20℃~200℃
线速度：≤20m/Sec
Mediums to be sealed：Water , oil , etc. moderate corrosive and below medium
Pressure in the sealed chamber：≤3MPa
Temperature in the sealed chamber：-20℃~200℃
Linear velocity：≤20m/Sec
59U 58U
型号：
技术参数：
被密封介质：水、油、中等以下腐蚀性介质
密封腔压力：≤1MPa
密封腔温度：-20℃~200℃
线速度：≤20m/Sec
Mediums to be sealed：Water , oil , etc. moderate corrosive and below medium
Pressure in the sealed chamber：≤1MPa
Temperature in the sealed chamber：-20℃~200℃
Linear velocity：≤20m/Sec
527 528
型号：
技术参数：
被密封介质：水、油、中等以下腐蚀性介质
密封腔压力：≤1MPa
密封腔温度：-20℃~150℃
线速度：≤15m/Sec
Mediums to be sealed：Water , oil , etc. moderate corrosive and below medium
Pressure in the sealed chamber：≤1MPa
Temperature in the sealed chamber：-20℃~150℃
Linear velocity：≤15m/Sec
E7S
型号：
技术参数：
被密封介质：水、油等弱腐蚀性介质
密封腔压力: ≤ 2.5 MPa
密封腔温度：-50℃~220℃
线速度：≤ 20m/Sec
MAIN CHARACTERISTICS:
Mediums to be sealed: Water ,oil ,etc.weak corrosive medium
Pressure in the sealed chamber ： ≤ 2.5 MPa
Temperature in the sealed chamber：-50℃~220℃
Linear velocity：≤ 20m/Sec
T7
型号：
技术参数：
被密封介质：水、油、等弱腐蚀性介质
密封腔压力：≤1.5MPa
密封腔温度：-50℃~220℃
线速度：≤20m/Sec
Mediums to be sealed:Water,oil,etc. weak corrosive medium
Pressure in the sealed chamber：≤1.5MPa
Temperature in the sealed chamber：-50℃~220℃
Linear velocity：≤20m/Sec
T3
型号：
技术参数：
被密封介质：水、油等弱腐蚀性介质
密封腔压力：≤1MPa
密封腔温度：-20℃~180℃
线速度：≤10m/Sec
Mediums to be sealed:Water,oil,etc. weak corrosive medium
Pressure in the sealed chamber：≤1MPa
Temperature in the sealed chamber：-20℃~180℃
Linear velocity：≤10m/Sec
T2
型号：
技术参数：
被密封介质：水、油、等弱腐蚀性介质
密封腔压力：≤1MPa
密封腔温度：-20℃~180℃
线速度：≤15m/Sec
Mediums to be sealed:Water,oil,etc. weak corrosive medium
Pressure in the sealed chamber：≤1MPa
Temperature in the sealed chamber：-20℃~180℃
Linear velocity：≤15m/Sec
